Detail view
- 2 and 4 analog channel models
- 100 MHz, 200 MHz, 350 MHz, 500 MHz, 1 GHz bandwidth models
- Bandwidth is upgradable (up to 1 GHz)
- Up to 5 GS/s sample rate
- 10 M record length on all channels
- >280,000 wfm/s maximum waveform capture rate
- Standard passive voltage probes with 3.9 pF capacitive loading and 250 MHz, 500 MHz or 1 GHz analog bandwidth
- Spectrum Analyzer
- Frequency range: 9 kHz - 1 GHz (standard) or 3 GHz (optional)
- Ultra-wide capture bandwidth up to 3 GHz
- Arbitrary Function Generator (optional)
- 13 predefined waveform types
- 50 MHz waveform generation
- 128 k arbitrary generator record length
- 250 MS/s arbitrary generator sample rate
- Digital Channels (optional)
- 16 digital channels
- 10 M record length on all channels
- 121.2 ps timing resolution
- Serial Bus Decode, Triggering and Search (optional)
- Serial bus support for I2C, SPI, RS-232/422/485/UART, USB 2.0, CAN, CAN FD, LIN, FlexRay, MIL-STD-1553, ARINC429, and Audio standards
- Digital Voltmeter / Frequency Counter (Free with product registration)
- 4-digit DC, AC RMS, and DC+AC RMS voltage measurements
- 5-digit frequency measurements
Specification
Option
Configure your 3 Series MDO by adding options
Instrument options
- 3-AFG
- Arbitrary Function Generator with 13 predefined waveforms, arbitrary waveform generation, and frequency and amplitude modulation.
- 3-MSO
- 16 digital channels; includes P6316 digital probe and accessories.
- 3-SA3
- Spectrum analyzer; frequency range from 9 kHz to 3 GHz and capture bandwidth to 3 GHz.
- 3-SEC
- Enhanced instrument security to enable password protected control of turning on/off all instrument ports and instrument firmware update functionality.
Bandwidth options
Choose the bandwidth you need today by choosing one of these bandwidth options. You can upgrade it later by purchasing an upgrade kit.
- 3-BW-100
- 100 MHz Bandwidth for analog channels, 1 GHz spectrum analyzer standard
- 3-BW-200
- 200 MHz Bandwidth for analog channels, 1 GHz spectrum analyzer standard
- 3-BW-350
- 350 MHz Bandwidth for analog channels, 1 GHz spectrum analyzer standard
- 3-BW-500
- 500 MHz Bandwidth for analog channels, 1 GHz spectrum analyzer standard
- 3-BW-1000
- 1 GHz Bandwidth for analog channels, 1 GHz spectrum analyzer standard
Power cord and plug options
- Opt. A0
- North America power plug (115 V, 60 Hz)
- Opt. A1
- Universal Euro power plug (220 V, 50 Hz)
- Opt. A2
- United Kingdom power plug (240 V, 50 Hz)
- Opt. A3
- Australia power plug (240 V, 50 Hz)
- Opt. A5
- Switzerland power plug (220 V, 50 Hz)
- Opt. A6
- Japan power plug (100 V, 50/60 Hz)
- Opt. A10
- China power plug (50 Hz)
- Opt. A11
- India power plug (50 Hz)
- Opt. A12
- Brazil power plug (60 Hz)
- Opt. A99
- No power cord
